| Plug and Play TA500 is easy to operate, connect it to the power source and it’s ready to roll! Comes with in-built battery, you can make it portable for your convenience. |
| Easy Data Management IP communication and USB Flash disk are available for your choice of connectivity |
| Versatile and Secured Verification TA500 gives you a variety of verification options such as fingerprint, password or card, or combination of options, providing you security and versatility you need. |
| Get Your Money’s Worth This model was designed to offer biometrics solution economically, giving you efficiency and performance without putting a hole in your pocket. |
Intuitive Navigation
|
| Sturdy Exterior Made from robust materials, TA500 can stand the wear and tear for years to come and it comes with 3 years limited warranty. |
| Small in Size, Large in Storage The compact TA500 can contain up to 2,000 fingerprints and 80,000 transaction logs, more than sufficient for your office requirements. |
| Manage Data Easily TCMS V3 is loaded with useful features complete with various reports for your business. Its data integration to 3rd party software is made available through the readily available SDK. |
| Layout Plan |
| System Communication |
| for illustration only ** |
| SPECIFICATIONS | |
| MODEL | TA500 |
| SURFACE FINISHING | Acrylonitrile butadiene styrene (ABS) & Polycarbonate (PC |
| TYPE OF SCANNER | Non coated optical scanner |
| MICROPROCESSOR | 360 MHz |
| MEMORY | 128 MB flash memory & 16 MB SDRAM |
| ALGORITHM | BioBridge VX 10.0 |
| DIMENSION (L X W X H), mm | 184 x 38 x 134 |
| STORAGE | |
| • Fingerprint templates | 2000 |
| • Cards | Made to order |
| • Transactions | 80000 |
| ENROLLMENT & VERIFICATION | |
| • Methods | Fingerprint (1:1, 1:N) & password (Optional RFID card) |
| • Recommended Fingerprint per user ID | 2 (Max 1000 user ID) |
| • Fingerprint placement | Any angle |
| • Verification time (sec) | < 1 |
| • FAR (%) | < 0.0001 |
| • FRR (%) | < 1 |
| CARD TECHNOLOGY | |
| • RFID: 64-bit, 125kHz, RF output power (EN300-330) | Made to order |
| • MIFARE: MFIS50/S70, 13.56MHz | Make to order |
| COMMUNICATIONS | |
| • Method | TCP/IP, USB disk |
| OPERATING ENVIRONMENT | |
| • Temperature (°C) | 0 ~ 45 |
| • Humidity (%) | 20 ~ 80 |
| • Power input | 12VDC1.5A |
| TIME ATTENDANCE | |
| • Siren | Internal and external |
| • Work codes | Yes |
| MULTIMEDIA | |
| • Greeting Voice | Yes |
| • Display | 2.8" 3k color TFT screen |
| • Photo ID | Yes |
| • Internal backup battery | Yes (2-hours working, 4-hours standby) |
| VOICE / DISPLAY LANGUAGE (TERMINAL) | English (Standard), Arabic, Indonesian,
Vietnamese, Spanish, Portuguese (Portugal), Russion, Thai, Turkish, French, Persian. Other languages are available upon request. |
| SOFTWARE LANGUAGE | Arabic, Bulgarian, Chinese (Simplified), Chinese (Traditional), English, French, German, Hindi, Indonesian, Kurdish, Malay, Persian, Portuguese, Russian, Spanish, Thai, Vietnamese |
| NOTE: Specifications are subject to change. Check http://product.fingertec.com for latest product information |
| *N/A: Not applicable |
 |
| Packaging Dimension (mm) : 245 (L) x 90 (W) x 225 (H) Weight : 1kg |
 |
 |
 |
 |
 |
 |
