| Small, Yet Loaded with
Capacity Kadex and m-Kadex can store a whopping total of 30000 users, and 50000 transaction logs. |
| Combine Your Verification
Methods Opt for a combination of verification methods to secure your workplace further. Choose the card and password verification with the Kadex for tighter security. |
| Manage Your Data Easily Administration is easy with the Ingress software application. Ingress allows you to remotely manage door activity of all connected terminals, while containing time attendance functions for attendance monitoring. |
| Simple Administrator
Management & Enrollment m-Kadex’s simple outlook is complimented with a simple management system. Just swipe your administrator card to enroll, delete, or reset the terminal. |
Value for Money
|
| Manage Your Shift Workers Kadex and m-Kadex can be programmed with a total of 50 time zones – perfect for companies with shift work. |
| Built-In Alarm Increase the security at your workplace by installing an external alarm, and be alerted during unexpected scenarios such as break-ins and fire emergencies. |
| Easy Data Management All you need is a USB flash disk to transfer transaction logs to your computer. It is that easy! |
| Layout Plan |
| System Communication |
| for illustration only |
| SPECIFICATIONS | ||
| MODEL | Kadex | m-Kadex |
| SURFACE FINISHING | Acrylonitrile butadiene styrene (ABS) | Polycarbonate |
| TYPE OF ANTENNA | RFID | |
| MICROPROCESSOR | 400 MHz | |
| MEMORY | 8 MB flash memory & 32 MB SDRAM | 4 MB flash memory & 32 MB SDRAM |
| PUSH TECHNOLOGY | Yes | N/A |
| ALGORITHM | BioBridge VX 9.0 | |
| PRODUCT DIMENSION (L X W X H), mm | 92 x 48 x 137 | 92 x 29 x 134 |
| STORAGE | ||
| • Cards | 30000 | |
| • Transactions | 50000 | |
| ENROLLMENT & VERIFICATION | ||
| • Methods | Card & password | Card |
| • Card per user ID | 1 | |
| • Reading distance, mm | 40 ~ 80 (RFID, HID), 30 ~ 50 (Mifare) | |
| • Veri cation time (sec) | <1 | |
| CARD TECHNOLOGY | ||
| • RFID: 64-bit, 125kHz, RF output power (EN300-330) | Yes | |
| • MIFARE: MFIS50/S70, 13.56MHz | Make to order | |
| • HID: HID 1325, 26-bit, 125kHz | Make to order | |
| COMMUNICATIONS | ||
| • Method | TCP/IP, RS232, RS485, USB disk | |
| • Baud rates | 9600, 19200, 38400, 57600, 115200 | |
| • Wiegand | 26-bit input / output | |
| OPERATING ENVIRONMENT | ||
| • Temperature (°C) | 0 ~ 45 | |
| • Humidity (%) | 20 ~ 80 | |
| • Power input | DC 12V 2A | |
| TIME ATTENDANCE | ||
| • Work codes | Yes | N/A |
| MULTIMEDIA | ||
| • Voice | Yes | N/A |
| • Display | Black and White | N/A |
| • Short messaging | Yes | N/A |
| ACCESS CONTROL | ||
| • EM lock driving output | DC 12V 3A / relay output | |
| • Alarm output | NO / NC | |
| • Anti passback | Yes | |
| VOICE / DISPLAY LANGUAGE (TERMINAL) (only for Kadex) | English (Standard), Arabic, Malay, Indonesian, Chinese Traditional / Simplified, Cantonese, Thai, Vietnamese, Korean, Spanish, Portuguese Portugal / Brazil, Polish, French, Russian,
German, Italian, Turkish, Persian, Slovak, Greek, Dutch, Hebrew, Romanian, Bulgarian. Other languages are available upon request |
|
| SOFTWARE LANGUAGE | English (Standard), Arabic, Bulgarian, Chinese (Simplified/Traditional), French, German, Hindi, Indonesian, Kurdish, Malay, Persian, Portuguese, Russian, Spanish, Thai, Vietnamese | |
| NOTE: Specifications are subject to change. Check http://product.fingertec.com for latest product information |
| *N/A: Not applicable |
 |
| Packaging Kadex Dimension (mm) : 225 (L) x 72 (W) x 168 (H) Weight : 0.80 kg m-Kadex |
