Full Colour Screen
Treat your eyes to a full colour TFT screen! Display pictures, corporate advertisements, screen savers and much more on the color screen of the terminals. |
|
 |
Built-In Alarm
Increase the security at your workplace by installing an external alarm, and be alerted during unexpected scenarios such as break-ins and fire emergencies |
|
| |
|
 |
Easy Terminal Syncing
With the option of TCP/IP, RS485 / RS232, USB flashdisk, or even WiFi (upon request), syncing your terminal is even easier than you think! |
|
 |
Function Keys
Program these keys to take you to commonly used functions in just one step. Did we mention that we make things easy? |
|
| |
|
 |
Simple Workcodes for Attendance Monitoring
Give your staff some flexibility by allowing them to report their attendance status by simply punching in a 2-digit code into the terminals. |
|
 |
Superb Capacity
With the latest precision algorithm, fingerprint scanning does not only become quicker and more accurate, but it can also hold up to 12,000 fingerprint templates and 200,000 transaction logs. |
|
| |
|
 |
A Variety of Verification Methods
Although its recommended that you use fingerprint verification for more authentic attendance and access control functions, the terminals also offer options for you to verify using a card or password, or even a combination of the two! |
|
 |
Manage Your Data Easily
Administration is easy with the bundled software! FingerTec’s TCMS V2 software allows you to generate reports, monitor attendance, and integrate FingerTec with a third party system. |
|
|
| |
| Layout Plan |
| System Communication |
| for illustration only |
 |
| |
| Installation Diagram (for Q2i only) |
| for illustration only |
 |
| |
| Specifications |
| MODEL |
Q2i |
TA200 Plus |
| SURFACE FINISHING |
Acrylonitrile Butadiene Styrene (ABS) |
| TYPE OF SCANNER |
Optical |
| PROCESSOR |
800 MHz microprocessor |
| MEMORY |
256MB flash memory and 64MB SDRAM |
| ALGORITHM |
BioBridge VX 9.0 / VX 10.0 |
| PRODUCT DIMENSION (L X W X H), mm |
200 x 56 x 160 |
| STORAGE |
| • User Capacity |
10000 |
| • Transaction |
200000 |
| ENROLLMENT & VERIFICATION |
| • Methods |
Fingerprint (1:1, 1:N), Card & Password |
| • Recommended Fingerprint per user ID |
2 |
| • Fingerprint placement |
Any angle |
| • Verification time (sec) |
< 1 |
| • FAR (%) |
< 0.0001 |
| • FRR |
< 1 |
| CARD TECHNOLOGY |
| • RFID: 64-bit, 125kHz, RF output power (EN300-330) |
Yes |
| • MIFARE: MFIS50/S70, 13.56MHz |
Made to order |
| • HID: HID 1325, 26-bit, 125kHz |
Made to order |
| COMMUNICATIONS |
| • Method |
TCP/IP, RS232, RS485, USB flash disk, (Optional: WiFi, GPRS & 3G) |
TCP/IP, USB flash disk (Optional: RS232, RS485, POE, WiFi & GPRS. 3G only applicable to non-POE devices) |
| • Baud rates |
9600, 19200, 38400, 57600, 115200 |
| • Wiegand |
26-bit input/output |
N/A |
| OPERATING ENVIRONMENT |
| • Temperature (°C) |
0 ~ 45 |
| • Humidity (%) |
20 ~ 80 |
| • Power input |
DC 12V 3A |
DC 5V 2A |
| TIME ATTENDANCE |
| • Siren |
Built- in (Optional - External) |
| • Work codes |
Yes |
| MULTIMEDIA |
| • Greeting voice |
Yes |
| • Display |
3.5” 65k color TFT screen |
| • Short messaging |
Yes |
| ACCESS CONTROL |
| • EM lock driving output |
DC12V 3A / Relay output |
N/A |
| • Alarm output |
NO/NC |
| • Antipassback |
Yes |
| VOICE / DISPLAY LANGUAGE (TERMINAL) |
English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Russian, German, Italian, Turkish, Persian. Other languages are available upon request. |
| SOFTWARE LANGUAGE |
English, Arabic, Arabic (Kuwait), Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Thai, Vietnamese, Korean, Spanish, Portuguese (Portugal), Portuguese (Brazil), Polish, French, Russian, German, Italian, Turkish, Persian, Lithuanian |
|
| |
 |
Packaging
Q2i
Dimension (mm): 245(L) x 90(W) x 225(H)
Weight: 2.9kg (with AdapTec AC), 1.8kg (without AdapTec AC)
TA200 Plus
Dimension (mm): 245(L) x 90(W) x 225(H)
Weight: 1.7kg |
|
|
|
|
