Integrate with WindowsBased Solutions
Use the OFIS-Z client with existing 32-bit and 64-bit Windows-based solutions as a higher level of security login instead of using a less secure password.
Password Free
With the number of online accounts available, remembering passwords can be a hassle. Reduce some burden from your staff by using fingerprints as a password for internal systems.
Manage Your Application Securely
With the OFIS Server, you get 6 OFIS-Z clients for setting up your application, integrating fingerprint solutions for either security control, or an online attendance solution.
Integrated Programming Language
OFIS SDK supports the common programming languages such as VB, MS VC++, Delphi, MS ASP, VB.NET, ASP, etc, as well as comes with several written sample applications.

Centralized Fingerprint Database
Capture users' fingerprints and centralize them in the ODBC compatible database for easy remote identity verification.


Easy Integration
The program interface of the OFIS software uses Active X, enabling easy integration of FingerTec with a third party system.
Precise Recognition
The OFIS-Z reader uses minutiae matching technology with the latest VX10.0 algorithm instead of fingerprint image scanning, ensuring that important fingerprint information cannot be stolen and duplicated.
Plug & Play
The OFIS-Z reader is small and portable, much like a desktop mouse which means no more clutter and no more hassle!
LAYOUT PLAN
Online Fingerprint Identification Environment
    For illustration only
MINIMUM SYSTEM REQUIREMENTS
OFIS-Z Server Module(For Online Identification)
•
•
•
•
•
•
•
IBM compatible PC
Pentium III 450 or above
256MB RAM
15MB for server module installation (Storage varies upon the number of fingerprints stored)
Standard mouse and keyboard
MS Windows XP and above with IIS support

OFIS-Z Client Module(For Windows-Based Solutions & Online Identification)
•
•
•
•
•
•
•
•
IBM compatible PC
Pentium III 450 or above
64MB RAM
5MB for client module installation
Standard mouse and keyboard
1 x USB port for FingerTec OFIS-Z Scanner
MS Windows XP and above with Internet Explorer (IE 6)

SPECIFICATIONS
• MODEL OFIS-Z
• ALGORITHM BioBridge VX 9.0 / VX 10.0
• SUPPORTING OS 32/64-bit Windows XP, Windows Vista, Windows 7, 8, 10 and Server 2008
• PIXEL RESOLUTION 512 dpi (average x, y over the scanning area)
• SCAN CAPTURE AREA, MM 15 x 18
• SCAN DATA 8-bit of grayscale (256 levels of gray)
• READER SIZE (APPROXIMATE) (L X W X H), MM 45 x 78 x 40
• COMPATIBILITY USB 1.0, 1.1, 2.0 (Full speed) specifications
• OS/BROWSER MS Windows/ MS Internet Explorer (IE 9)
• POWER SUPPLY 5.0V +/- 0.25V, USB supply
• OPERATING TEMPERATURE (°C) 0 ~ 55
• OPERATING HUMIDITY (%) 20 ~ 80 non-condensing
• STANDARD FCC CLASS FCC Class B, CE, USB
• USAGE Indoor, home and office use
• SOFTWARE info Manager
NOTE: Specifications are subject to change. Check http://product.fingertec.com for latest product information


Packaging
Dimension (mm) : 173 (L) x 60 (W) x 135 (H)
Weight : 0.00 kg
