| 4 Unlocking Credentials Unlock doors using password, card, mechanical key or your smartphone’s Bluetooth connection. |
| 3 User Group Types Gain better access control management with FingerTec Smart Lock User Group Types: Admins, Regular Users and Temporary Users. |
| User Capacity Register as many users as you desire within TimeTec Security App and i-Neighbour App through a smartphone. |
| Normally Open Type This particular setting caters for offices or areas with regular visitor access. Thereby, reducing instances resulting in entrances being ‘bottlenecked’. |
| Optimal Battery Life Only 4 AA alkaline batteries are required to operate over 6000 accesses. Hence, approximately a year of use before you are faced with the low-battery warning indication. |
| Slim Design SL-70B employs a simple design structure which allows it to be installed in almost any strategic location effortlessly thus making it a robust product. |
| Emergency Override Key In case of an emergency like losing a smartphone. SL-70B comes with a concealed override key for accessing the door. |
| Downloadable App Android and iOS Apps for i-Neighbour and TimeTec Security are available for those who prefer to use a smartphone in terms of door access. |
| LAYOUT PLAN |
| SPECIFICATIONS | |
| MODEL | SL-70B |
| SURFACE FINISHING | RFID |
| ALGORITHM | Biobridge VX 10.0 |
| RESOLUTION OF SCANNER (dpi) | 560 |
| PRODUCT DIMENSION (L X W X H), mm |
Front Assembly: Front View 62 x 30 x 142 Back Assembly: Front View 60 x 45 x 155 |
| • Thickness of door, mm | 38 - 50 |
| • Door latch type | Single deadbolt |
| • Inner lock switch | Yes |
| STORAGE | |
| • Password | 100 |
| • Card | 100 |
| • Bluetooth | Unlimited users for TimeTec Security App & i-Neighbour App |
| BLUETOOTH VERIFICATION | |
| • Communication | Bluetooth 4.0 |
| OPERATING ENVIRONMENT | |
| • Temperature (°C) | - 20 to – 55 |
| • Humidity (%) | 20 ~ 80 |
| • Power input | 4 x1.5v AA battery for 6000 operations |
| • Power consumption – static (µA) | < 35 |
| • Power consumption – activity (mA) | < 135 |
| • Power consumption – driving (mA) | < 200 |
| • Antistatic voltage (V) | > 1500 |
| • Low battery warning voltage (V) | < 4.5 |
| BACKUP UNLOCK MECHANISM | Battery & mechanical key |
| MOBILE OS | Android 4.0.2 and above, iOS 8.0 and above |
| APP LANGUAGE | Arabic, Chinese Simplified and Traditional, English, Hindi, Indonesian, Malay, Nepali, Spanish, Thai, Turkish, Vietnamese. Other languages are available upon request |
| NOTE: Specifications are subject to change. Check http://product.fingertec.com for latest product information |
 |
| Packaging Dimension (mm) : 245 (L) x 90 (W) x 225 (H) Weight : 2.8kg |
 |
 |
 |
 |
 |
 |
 |
